Random orbital polisher – Bigfoot duetto LHR12E
LHR12E
All-in-one sanding and polishing system for painted surfaces
Duetto is equally effective working with soft or interface backing pads teamed with micro-abrasives during the defect correction step or with foam polishing pads and compounds during the polishing stage. Extensive research on random orbital dynamics and exhaustive testing resulted in the choice of a 12mm orbit for Duetto. This orbit length greatly improves the surface rectification abilities of the latest generation of microabrasive discs. The combination of duetto and microabrasives is especially effective when smoothing orange peel or significant defects. The finish generated by this combination is both homogeneous and predictable, with no deep sanding marks.
The use of microabrasive discs to correct severe defects creates a surface that is easily polished, radically reducing the overall time of the full correction process. Duetto is so well balanced and low in vibration that the operator can easily control the sanding step by simply guiding duetto over the surface. The ability of the operator to control the tool so efficiently minimizes the chances of creating rough and uneven surfaces that require time-consuming rework.
Duetto has several design features that make it uniquely operator friendly.
The anti-spinning device reduces the chances of operator error even for a novice technician. The front hand grip allows the operator to place his/her hand at the virtual balance center of the tool and keeps vibration to a minimum.
The electronic module has built-in torque control, reducing the need for the operator to apply significant downward vertical pressure. Another unique duetto feature is the rubber support that allows the operator to place duetto on a workbench without the abrasive disc touching a surface that might contain contaminants that could transfer to the workpiece during the sanding process. Compatible with microabrasive discs and the appropriate 5” interface pad.
Photos
Videos
Available kits
LHR12E/STD
LHR12E/BOX
Systainer Case(9.CASEIII)
D-A COARSE polishing compound 250ml( 9.DACOARSE)
UNO PROTECT polishing compound 250ml(9.PROTECT)
2x Wool Polishing Pad COARSE Ø130 mm(9.NW130H)
2x Wool Polishing Pad FINE Ø130 mm(9.NW130M)
BIGFOOT Claw pad tool(9.BF7001)
3x Abrasives X-Cut P 2000 Ø125mm(9.45401)
3x Abrasives X-Cut P 3000 Ø125mm(9.45403)
Microfiber cloth Blue( 9.BF9050)
Microfiber cloth Yellow(9.BF9060)
LHR12E/BAS
D-A COARSE polishing compound 250ml(9.DACOARSE)
D-A FINE polishing compound 250ml(9.DAFINE)
Wool polishing pad COARSE Ø130 mm(9.NW130H)
D-A FINE foam polishing pad Ø130-150mm - Ø5”-6”( 9.DA150M)
Microfiber cloth Blue( 9.BF9050)
Microfiber cloth Yellow(9.BF9060)
Cable Clamp (9.Z1024)
LHR12E/LUX
D-A COARSE polishing compound 250ml(9.DACOARSE)
D-A FINE polishing compound 250ml(9.DAFINE)
Wool polishing pad COARSE Ø130 mm(9.NW130H)
Wool polishing pad FINE Ø130 mm(9.NW130M)
D-A COARSE foam polishing pad Ø130-150mm - Ø5”-6”(9 .DA150H)
D-A FINE foam polishing pad Ø130-150mm - Ø5”-6”( 9.DA150M)
abrasive starter ki(9.45401/M)
Microfiber cloth Blue(9.BF9050)
Microfiber cloth Yellow(9.BF9060)
Microfiber cloth White( 9.BF9070)
Cable Clamp(9.Z1024)
BIGFOOT apron( 9.Z868)
BIGFOOT tools bag(9.Z883/BF)
Technical data
Backing pad thread | M8 |
Speed control | • |
Weight (Kg) | 2,6 |
R.P.M. | 4000-5500 |
Power (W/hp) | 400 |
Ø orbit (mm) | 12 |
Ø backing pad (mm) | 125 |
